MONOCRISTALLINE 250 WP – SOLANA

Rp3500000
Category: Tags:
Ratings:
+
Deskripsi

Description

Download Datasheet

MONOCRISTALLINE 250 WP – SOLANA

Download datasheet panel surya Monocristalline 250 WP.

Panel Surya Monocristalline 250 WP – SOL-M24250W

Fitur Utama Panel Surya Monocristalline 250 WP – SOL-M24250W:
  • Cell. The hi-efficiency of mono and poly solar cells ensure adequate power for panels.
  • Glass. Low-iron tempered glass, 3.2mm thiickness with higher reflectivity.
  • EVA. Higher transmission rate, antioxidant capacity and temperature resistance, no expansion or contraction.
  • Back Film. Increase efficiency of modules slightly and reduce module’s temperature. Aging resistance, corrosion resistance and air tight.
  • Alumunium Frame. Using the framework of the anodized alumunium frame with high intensity, mechanical shock resistance capacity.
  • Modules withstand extremely (temperature, load, and impact) TUV Certification.
Panel Surya Berkualitas Yang Bisa Diandalkan
  • 100 % EL double-inspection ensure modules are defects free
  • IP65 junction box long-term weather endurance.
  • Certificate ISO, IEC 61215, IEC 61730, CE, CQC.
Data Teknis Panel Surya Monocristalline 250 WP:
  • Maximum Power at STC* (Pmax): 250 W
  • Short Circuit Current (Isc): 8,75 A
  • Open Circuit Voltage (Voc): 36,3 V
  • Maximum Power Current (Imp): 8,25 A
  • Maximum Power Voltage (Vmp): 30,3 V
  • Module Efficiency: 15,37 %
  • Power Tolerance: 0 – +3 %
  • Maximum system voltage: VDC 1000 V
  • Maximum Series Fuse: 15 A
  • Operating Temperature: -40 to +85 °C

Data Dimensi Dan Berat Panel Surya Monocristalline 250 WP:

dimensi panel surya 250 wp mono solana

Dimensi Panel Surya: 1670 mm x 992 mm x 35 mm
Berat Panel Surya: 17,5 kg

*STC: irradiance 1000 W/m²




Jual Panel Surya untuk Aplikasi Pompa Air Tenaga Surya (PATS)
Jual Panel Surya untuk Aplikasi Pembangkit Listrik Tenaga Surya (PLTS)
